Case: Upper limb radiograph #49082159
Upper limb Intermediate
Read this radiograph systematically before revealing the answer. What is the main abnormality?
Image: James Heilman, MD via Wikimedia Commons · CC BY-SA 4.0 · source · resized and converted to WebP
Tip: scroll or pinch to zoom, drag to pan, and try Invert.
Answer: Acromioclavicular joint dislocation
What to look for in acromioclavicular joint dislocation
- Widened AC joint and coracoclavicular distance.
Description by the image author (may be in another language): Grade 3 AC joint seperation
Educational case. The diagnosis comes from the image's documented source; the "what to look for" list describes the condition in general and is not a report of this individual image.
